Search found 193 matches

by OnTheChip
Sun Sep 13, 2020 8:24 am
Forum: KA-T Tech. Advanced
Topic: Hitting a wall at 4500rpm [SOLVED]
Replies: 11
Views: 357

Re: Hitting a wall at 4500rpm

Your best bet is to post this in the Nismotronic FB group:

https://www.facebook.com/groups/145162022225980

Lots of experienced Nismotronic users there and John Kerr monitors it regularly.
by OnTheChip
Sat May 23, 2020 7:36 am
Forum: KA-T Tech. Advanced
Topic: 615cc inj stock ecu
Replies: 26
Views: 1309

Re: 615cc inj stock ecu

It could be an injector latency issue. At idle, the latency is a large portion of total injector pulse width.
When coolant temp reaches 175F, ECU goes into closed loop and short term fuel trim adds fuel.
by OnTheChip
Mon Jun 24, 2019 9:33 am
Forum: ECU Tuning
Topic: Deka 80lb injectors
Replies: 2
Views: 2076

Re: Deka 80lb injectors

by OnTheChip
Tue Mar 19, 2019 8:09 am
Forum: FWD KA-T
Topic: Run fuel pump with switch ?
Replies: 1
Views: 4234

Re: Run fuel pump with switch ?

The answer to your question is "B : the fuel injectors do not open.".
by OnTheChip
Sat Oct 21, 2017 10:08 am
Forum: ECU Tuning
Topic: S14 internal coil distirbutor wiring for microsquirt/ms3?
Replies: 2
Views: 2108

Re: S14 internal coil distirbutor wiring for microsquirt/ms3

I found the diagrams you need in the '97 S14 FSM EC (ECCS) manual under the descriptions for trouble shooting DTC P1320 for the ignition signal and DTC P0340 for cam position sensor. Your pin numbers are correct and connect as follows: dist# -> destination 1 -> ecu pin #1 2 -> ground 3 -> ecu pin #4...
by OnTheChip
Sat Mar 18, 2017 9:01 am
Forum: ECU Tuning
Topic: nismotronic ka24de cop help
Replies: 35
Views: 20189

Re: nismotronic ka24de cop help

Nicely done! Thanks!
by OnTheChip
Fri Oct 02, 2015 7:39 am
Forum: KA-T Tech. Basic
Topic: Car running very rich
Replies: 7
Views: 1485

Re: Car running very rich

Have you pulled any codes from the ECU?
Tried running with MAF unplugged?
by OnTheChip
Thu Jul 16, 2015 10:18 am
Forum: ECU Tuning
Topic: ECU pin replacement
Replies: 1
Views: 1020

Re: ECU pin replacement

You can use one of the otherwise unused pins, such as any of the consult wires on pins 7, 14, or 15.
by OnTheChip
Mon Jun 29, 2015 8:30 am
Forum: KA-T Tech. Advanced
Topic: No IAVC, adjusting TPS
Replies: 8
Views: 2032

Re: No IAVC, adjusting TPS

What calibration changes did you have to make through the software?
by OnTheChip
Sun Jun 28, 2015 6:34 am
Forum: KA-T Tech. Advanced
Topic: No IAVC, adjusting TPS
Replies: 8
Views: 2032

Re: No IAVC, adjusting TPS

street_240sx wrote:I havent had an iacv for 6 years. Adjust the tb open some then you adjust the tps according to fsm. Thankfully my megasquirt allows me to calibrate it through the software
What changes did you need to make for good idle control without an IACV?
by OnTheChip
Fri Jun 19, 2015 6:35 am
Forum: ECU Tuning
Topic: What should MAF load be at?
Replies: 2
Views: 1197

Re: What should MAF load be at?

Are there any DTCs set?
What base TCD are you using?
What MAF are you using?
What is the MAF load reading when idling?
What is the MAF Load Factor setting?
by OnTheChip
Wed Jun 17, 2015 3:18 pm
Forum: ECU Tuning
Topic: nismotronic ka24de cop help
Replies: 35
Views: 20189

Re: nismotronic ka24de cop help

The latest version of NismotronicSA has the fix for the COP Wizard to be able to run an S13 KA24DE (or B13 SR20DE) TCD on the SR20DET ECU and is now available for update. Be sure you have the latest version (3.25.0) before using the COP Wizard. If you are starting out with an S13 SR20DET base TCD, y...
by OnTheChip
Wed Jun 10, 2015 7:35 am
Forum: ECU Tuning
Topic: Nismotronic ECU Tuning
Replies: 1
Views: 1169

Re: Nismotronic ECU Tuning

There's a Nismotronic dealer in Fontana.
OSR Dyno Tuning
17338 Foothill Blvd
Fontana, CA 92335
(909)644-5722
http://www.osrdyno.com

Others: Nismotronic Dealers
by OnTheChip
Sun Feb 01, 2015 8:13 am
Forum: ECU Tuning
Topic: nismotronic ka24de cop help
Replies: 35
Views: 20189

Re: nismotronic ka24de cop help

Alonso wrote:Any updates on this?

I'm super close to starting my car with the DET ECU and Denso CBR coils. Is it possible to offset the timing within the software itself?
No, there is no "global" timing offset.
by OnTheChip
Mon Jan 19, 2015 9:51 am
Forum: KA-T Tech. Basic
Topic: Injector signal voltage?
Replies: 10
Views: 2181

Re: Injector signal voltage?

The injectors are powered straight from the battery through a fusible link, not through the ignition switch. The signal wire is open circuit until the ECU grounds it to complete the circuit and open the injector. With the volt meter across the injector contacts, you are looking at the voltage across...
by OnTheChip
Mon Nov 03, 2014 9:39 am
Forum: KA-T Chat
Topic: Nismotronic Standalone
Replies: 14
Views: 3530

Re: Nismotronic Standalone

The only small issue I see with nismotronic is that you have to use a S13 ecu, which brings up the price if you have an S14. But it seems that in the long run it's worth it with the added benefits. You don't need an S13 ECU with a KA24DE, unless you want to convert to COP. NismotronicSA will run a ...
by OnTheChip
Thu Oct 23, 2014 5:09 pm
Forum: ECU Tuning
Topic: ECU tuning options KA24DET
Replies: 7
Views: 4756

Re: ECU tuning options KA24DET

Yes, the wide band is definitely separate item :) Nismotronic looks like it would be perfect for me. Just to be clear: It supports the addition of a MAP sensor, IAT sensor, and boost solenoid, and wide band. Are the sensors used just for data logging, or are they fully functional in terms of map in...
by OnTheChip
Tue Oct 21, 2014 7:55 am
Forum: KA-T Chat
Topic: Nismotronic Standalone
Replies: 14
Views: 3530

Re: Nismotronic Standalone

Here are links to some Nismotronic info pages.... Main website: Nismotronic Website NismotronicSA details: NismotronicSA Package Software Download: Download NismotronicSA Software Demo NismotronicSA Help Documentation: NismotronicSA Help Nismotronic FB Group: Nismotronic FB Group Nismotronic FB Page...
by OnTheChip
Tue Oct 21, 2014 7:49 am
Forum: KA-T Tech. Basic
Topic: rich idle, lean throttle?
Replies: 10
Views: 2229

Re: rich idle, lean throttle?

You can use some peal-and-stick weather stripping foam stuck to the lid above the daughter board header to hold it in.
by OnTheChip
Tue Oct 21, 2014 7:41 am
Forum: KA-T Tech. Basic
Topic: rich idle, lean throttle?
Replies: 10
Views: 2229

Re: rich idle, lean throttle?

Thedriftbadger wrote:The whole daughter board fell out and was just laying inside the case.
That's not possible with a Nismotronic NEMU daughter board, There are stand-offs on the board to hold in positively. Maybe you have a basic 2-chip daughter board from J-K-Tuning?
by OnTheChip
Sat Oct 11, 2014 8:28 am
Forum: KA-T Chat
Topic: Cheap alternative for intercooler bead
Replies: 8
Views: 2354

Re: Cheap alternative for intercooler bead

Here's one I made a few years ago using an old ball bearing race.



by OnTheChip
Wed Aug 13, 2014 1:16 pm
Forum: ECU Tuning
Topic: Nistune Launch Control S13
Replies: 14
Views: 6772

Re: Nistune Launch Control S13

Right, but he left off the part that says "Nistune requires a special hardware programmer to reprogram the code portion into the Nistune hardware". That's why it's not working for you.
by OnTheChip
Wed Aug 13, 2014 7:44 am
Forum: ECU Tuning
Topic: Nistune Launch Control S13
Replies: 14
Views: 6772

Re: Nistune Launch Control S13

Launch control has to be implemented in the program, or code, portion of the bin. An .xdf file is a "data definition" file that tells the TunerPro program how to interpret the data, or tune, portion of a bin. Nistune requires a special hardware programmer to reprogram the code portion into the Nistu...
by OnTheChip
Tue Jul 29, 2014 8:25 am
Forum: ECU Tuning
Topic: nismotronic ka24de cop help
Replies: 35
Views: 20189

Re: nismotronic ka24de cop help

Don't go to any extra effort, but if possible, could you please post pics from the disk side showing the optical sensor and mounting tangs?

Thanks,
Dave
by OnTheChip
Mon Jul 28, 2014 1:40 pm
Forum: ECU Tuning
Topic: nismotronic ka24de cop help
Replies: 35
Views: 20189

Re: nismotronic ka24de cop help

Is it possible that you are using a KA24E (single cam) dizzy?
by OnTheChip
Mon Jul 28, 2014 8:42 am
Forum: ECU Tuning
Topic: nismotronic ka24de cop help
Replies: 35
Views: 20189

Re: nismotronic ka24de cop help

Thanks! Is the optical pickup inside the housing in the same location relative to the mounting slots?
by OnTheChip
Mon Jul 28, 2014 6:35 am
Forum: ECU Tuning
Topic: nismotronic ka24de cop help
Replies: 35
Views: 20189

Re: nismotronic ka24de cop help

thegr8one013: Do you happen to know how many teeth are on the distributor shaft? We may be able to resolve the issue in the ECU with the CAS Wizard.

Thanks,
Dave
by OnTheChip
Mon Jul 28, 2014 6:12 am
Forum: ECU Tuning
Topic: nismotronic ka24de cop help
Replies: 35
Views: 20189

Re: nismotronic ka24de cop help

I didn't mean to mislead and I'm very sorry you had problems. I was going by this disk (pic below), which has the same shaft/slot orientation as the SR20DET disk, and I knew the firing offset in the ECU is the same. http://www.supercars.net/gallery/132464/1497/645195.jpg As John says, we apologize f...
