Maxima coils- Bad experience

Post by wannaboost? » Sun Mar 17, 2013 6:48 pm

Ok everyone, I just wanted to share my story with the 95-99 Maxima coils for any of you looking into a coil-on-plug setup.

I initially went to the junkyard and got 7 coils (4 for use and 3 spares). Well, after getting my fresh engine started and setup on the dyno, they were giving us trouble at 18ish psi. We swapped 3 of them for my spares and it seemed to be fine and we made 400ish whp at 19psi. I then did a full drift test day at our local lot and it too seemed to be ok.

THEN, going into the first competition of the year, starting from practice, they wouldn't even hold 9 psi. We went to Vatozone and O'reallys and bought 4 new coils to make it through the day, but had no luck. After trying 11 Maxima coils, my tuner comes to the rescue with a set of Honda K series coils. They fit great, pin the same, and worked extremely well. We turned the boost way back up and had a blast that day.


Just thought I'd share my experience with these because they seemed to be such a great, cheap alternative.


Build.Boost.Break.Repeat.

Berserker
Dont Question My Nissan Knowledge
Posts: 823
Joined: Tue Sep 19, 2006 4:15 pm
Location: IL

Post by Berserker » Sun Mar 17, 2013 7:01 pm

I also had a few bad coils from the junkyard, but those maximas had 240k+ miles lol other then few bad coils they hold 28 psi 600 whp for me. All my coils are from almost 200k miles maxima :S
608 whp @ 27.25 psi powered by Precision6262

jackasspyro
240sx Wannabe
Posts: 166
Joined: Wed Jan 24, 2007 1:20 pm
Location: college station,tx
Contact:

Post by jackasspyro » Tue Mar 19, 2013 6:56 pm

why did you pick those over the ls coils

RosadoRacing
Dont Question My Nissan Knowledge
Posts: 540
Joined: Tue Apr 06, 2010 5:33 pm
Location: Bethlehem, PA
Contact:

Post by RosadoRacing » Tue Mar 19, 2013 7:29 pm

I think I had one bad coil and had 4 from a 200k last all yr plus few dyno runs at 665whp I now upgraded to 01 maxi coils that look beefier nicer n of course r newer im hoping to see a larger gap n better results I can tell right off the bat start ups are alot better. thats interesting the k series use the same plug n fit perfect upload some pics I know a guy who made 800whp on his b18 with a .020 gap s2000 coils don'tknow if that's what you have

User avatar
wannaboost?
Dont Question My Nissan Knowledge
Posts: 506
Joined: Fri Aug 01, 2008 9:17 pm
Location: DFW, Texas
Contact:

Post by wannaboost? » Wed Mar 20, 2013 8:48 pm

Yes, K series and S2k are the same. They don't use the same plug as maxima but they are pinned exactly the same. We did find that the plug is nearly the same and would fit with some trimming but I'd suggest just buying K series plugs.


Build.Boost.Break.Repeat.

User avatar
cleantune
Encyclopedia-Nissan
Posts: 1333
Joined: Sun Nov 25, 2007 9:12 pm
Location: 610

Re: Maxima coils- Bad experience

Post by cleantune » Sat Aug 16, 2014 10:01 am

.
I know this is kind of an "old" topic, but I was wondering.... do the K series coils just drop right into our KA engines? I mean length-wise and with the diameter of their "stem", do they reach the sparkplugs?

I found this pic, but its kind of blurry:

.
.
KA-T parts For SALE !!! >>viewtopic.php?f=19&t=63173&p=534184#p534184 <<

instagram: @cleantune / @siks_tehn

ViperGT
Knows Some Stuff About 240's!
Posts: 445
Joined: Fri Nov 11, 2011 1:26 am
Location: long beach

Re: Maxima coils- Bad experience

Post by ViperGT » Sat Aug 16, 2014 11:40 pm

what were your plug gaps?
in a datsun 510:
arias 8.8 .020
eagle rods
clevite bearings
ferrea/exhaust supertech/intake stk
supertech springs and retainers
bc valve guides v2 cams currently crower 288/288 (no good)
port and polish
arp head, main, rod bolts
osk timing
current: custom log mani, TIAL mvr,
later: ati SD garret gtx3071 currently in my possession looking for gtx3576
custom downpipe
lol:
sdaigle240 wrote:beat that thing like it owes you money.

RosadoRacing
Dont Question My Nissan Knowledge
Posts: 540
Joined: Tue Apr 06, 2010 5:33 pm
Location: Bethlehem, PA
Contact:

Re: Maxima coils- Bad experience

Post by RosadoRacing » Sat Aug 23, 2014 12:03 am

I run the 01 maxima coils at .016 gap 721whp 27psi the 95 are weaker n only made it to 665. I have the 04 3.5 coils I'll be trying next for 32psi that my tuner said are good to upwards of 800whp!!!!

User avatar
street_240sx
Belongs To The TOP CONTRIBUTING MEMBERS!
Posts: 1921
Joined: Sun Feb 10, 2008 7:31 pm
Location: 520 AZ
Contact:

Re: Maxima coils- Bad experience

Post by street_240sx » Sat Aug 23, 2014 9:23 am

I run ls1 coils, they work perfectly fine
03 evo8 gsr: stroker 2.3 ;)

04 evo8 gsr: totalled

96 integra gsr: sold

89 s13 coupe: stock dohc, gt3076, megasquirt

started 3/15/08, running 1/18/09, finally turbo 2/9/14 lmfao
